Description
The Pete and Jakes 1932 Ford Power Brake Assembly is a comprehensive solution for hot rodders looking to add modern stopping power to their classic frame. This kit moves the braking system under the floor for a clean engine bay, while the 7″ dual-diaphragm booster provides significantly more assist than a standard single-diaphragm unit.
High-Performance Boosting
-
7″ Dual Diaphragm Booster: Despite its compact size (necessary for under-floor clearance), the dual-diaphragm design provides the increased vacuum assist required for heavy vehicles or those equipped with four-wheel disc brakes.
-
Master Cylinder Included: Comes pre-matched with a dual-reservoir master cylinder, ensuring correct fluid volume and pressure for modern disc/drum or disc/disc setups.
-
Compact Footprint: Engineered to fit within the narrow confines of a 1932 Ford frame rail without interfering with the transmission or center X-member.
Integration and Hardware
-
Weld-On Mount: Includes a heavy-duty frame mount designed to be welded directly to the 1932 Ford chassis. This provides a rigid, flex-free platform for the brake pedal and booster assembly.
-
Brake Pedal: Includes a laser-cut brake pedal arm designed with the correct mechanical leverage ratio to work in harmony with the power booster.
-
Hardware: The kit typically includes the necessary pushrods and mounting hardware to connect the pedal to the booster.
Installation Note
Because this assembly mounts under the floor, you will likely need to install residual pressure valves (2-lb for disc, 10-lb for drum) to prevent fluid from draining back into the master cylinder, as the master cylinder will be sitting lower than the wheel cylinders/calipers.
